Cylindrical Lithium Polymer Batteries - Lithium Polymer Batteries Manufacture
Over 2,000+ in stock lithium polymer batteries for evaluate & mechanical design.
Cylindrical Lithium Polymer Batteries
– Lithium Polymer Batteries Manufacture
Cylindrical Lithium Polymer Batteries are stick shaped Lithium Polymer Batteries designed for tube space in electronics.Widely used in e-cigarettes, digital fishing floats,LED lights.
Cylindrical Lithium Polymer Batteries are good batteries for e-cigarette for it’s quite light weight,high capacity and wonderful suitable shape.Not only for this application, recently, it is also used for many new products such as digital fishing floats, smart pen.
Cylindrical Lithium Polymer Batteries specs:
Nominal voltage: 3.7 V ( or 3.8V)
Charging voltage: 4.2 V
- Discharging cut off voltage: 3.0V or 2.75V
- Charging cut off voltage: 4.2V
- PCM(protection circuit) Required: Yes.It can also be integrated into PCBA of the device.
- Capacity: custom
- Diameter: 5mm~20mm
- Length: 10mm~100mm
LiPol also have those special shape Lithium Polymer Batteries for your reference:
Highest Amperage 18650 Li-ion Battery
Cylindrical Lithium Polymer Batteries
Cylindrical Lithium ion Polymer Batteries
Cylindrical Lithium ion Polymer Batteries
600mAh Cylindrical Lithium Polymer Batteries LPR13450
600mAh Cylindrical Lithium Polymer Batteries LPR13450
1100mAh Cylindrical Lithium Polymer Batteries LPR16500
1100mAh Cylindrical Lithium Polymer Batteries LPR16500
850mAh Cylindrical Lithium Polymer Batteries LPR18350
850mAh Cylindrical Lithium Polymer Batteries LPR18350
550mAh Cylindrical Lithium Polymer Batteries LPC11530
550mAh Cylindrical Lithium Polymer Batteries LPC11530
400mAh Cylindrical Lithium Polymer Batteries LPC13300
400mAh Cylindrical Lithium Polymer Batteries LPC13300
Cylindrical Lithium Polymer Batteries
| Part Numbe | Capacity (mAh) | Power（Wh） | Resistance (mΩ) | Diameter (max) | Length (max) | Max Discharge Current |
|---|---|---|---|---|---|---|
| LPC25600 | 3300 | 12.21 | 40 | 25 | 63 | 20A |
| LPC23600 | 2800 | 10.36 | 40 | 23.2 | 61 | 20A |
| LPC23500 | 2400 | 8.88 | 40 | 23.2 | 52 | 20A |
| LPC20600A | 2300 | 8.51 | 40 | 20.8 | 61.5 | 20A |
| LPC19650 | 2250 | 8.33 | 30 | 19.2 | 65.5 | 20A |
| LPC18650A | 2100 | 7.77 | 60 | 18.5 | 65 | 1.2A |
| LPC20600B | 2000 | 7.4 | 40 | 19.6 | 61.5 | 20A |
| LPC18650F | 1950 | 7.22 | 60 | 17.5 | 67 | 3A |
| LPC19600B | 1950 | 7.22 | 30 | 19.2 | 60.5 | 20A |
| LPC18650B | 1900 | 7.03 | 40 | 17.5 | 67 | 15A |
| LPC18650C | 1900 | 7.03 | 40 | 18.3 | 66 | 20A |
| LPC18650H | 1900 | 7.03 | 40 | 18.3 | 67 | 15A |
| LPC18650I | 1900 | 7.03 | 40 | 18.3 | 66 | 20A |
| LPC19600A | 1900 | 7.03 | 40 | 19 | 61.5 | 20A |
| LPC20650 | 1900 | 7.03 | 40 | 19.4 | 67 | 30A |
| LPC22500 | 1900 | 7.03 | 40 | 22 | 52 | 25A |
| LPC18650E | 1850 | 6.85 | 40 | 18.5 | 67 | 15A |
| LPC20500A | 1800 | 6.66 | 40 | 20.3 | 52 | 15A |
| LPC17650 | 1700 | 6.29 | 40 | 17.5 | 66 | 15A |
| LPC18650D | 1700 | 6.29 | 40 | 18.3 | 67 | 30A |
| LPC18650G | 1700 | 6.29 | 40 | 17.4 | 67 | 20A |
| LPC20500B | 1700 | 6.29 | 40 | 20.3 | 52 | 20A |
| LPC21450 | 1700 | 6.29 | 40 | 21 | 45 | 15A |
| LPC22450 | 1700 | 6.29 | 40 | 22 | 47 | 20A |
| LPC16650 | 1600 | 5.92 | 80 | 16.5 | 69 | 1.2A |
| LPC18500D | 1600 | 5.92 | 40 | 17.8 | 53 | 5A |
| LPC19500 | 1600 | 5.92 | 40 | 19.3 | 52 | 15A |
| LPC20450A | 1600 | 5.92 | 40 | 20.6 | 47 | 15A |
| LPC18450B | 1500 | 5.7 | 35 | 18.3 | 45.5 | 1.5A |
| LPC20450B | 1500 | 5.55 | 40 | 20.6 | 47 | 15A |
| LPC18500A | 1450 | 5.37 | 40 | 17.8 | 53 | 15A |
| LPC18500C | 1450 | 5.37 | 40 | 18.3 | 53 | 15A |
| LPC18500E | 1450 | 5.37 | 40 | 17.8 | 52 | 15A |
| LPC18500F | 1400 | 5.18 | 40 | 18.2 | 50 | 15A |
| LPC22400 | 1400 | 5.18 | 40 | 22 | 41 | 20A |
| LPC18500B | 1350 | 5 | 40 | 18.3 | 52 | 20A |
| LPC23350 | 1340 | 4.96 | 40 | 23 | 35 | 15A |
| LPC13800 | 1300 | 4.81 | 50 | 13.1 | 80 | 2A |
| LPC16600B | 1300 | 4.81 | 80 | 15.8 | 62 | 1.2A |
| LPC17600 | 1300 | 4.81 | 40 | 17 | 59 | 15A |
| LPC18450A | 1250 | 4.63 | 40 | 18.3 | 47 | 15A |
| LPC18400C | 1225 | 4.53 | 30 | 18.3 | 41.5 | 3A |
| LPC16600A | 1200 | 4.44 | 80 | 15.8 | 61 | 1.2A |
| LPC16600C | 1200 | 4.44 | 40 | 15.8 | 62 | 10A |
| LPC17500A | 1200 | 4.44 | 40 | 17 | 52 | 15A |
| LPC17500B | 1200 | 4.44 | 40 | 17.5 | 52 | 20A |
| LPC13700B | 1100 | 4.07 | 80 | 13.5 | 72 | 1.2A |
| LPC16500B | 1100 | 4.07 | 40 | 16.2 | 52 | 10A |
| LPC18400B | 1050 | 3.89 | 40 | 18.3 | 41 | 15A |
| LPC20400 | 1050 | 3.89 | 40 | 19.5 | 41 | 20A |
| LPC13700A | 1020 | 3.77 | 80 | 13.5 | 72 | 1.2A |
| LPC13700C | 1020 | 3.77 | 80 | 13.3 | 72 | 10A |
| LPC16530 | 1000 | 3.7 | 50 | 15.5 | 53 | 5A |
| LPC22300 | 1000 | 3.7 | 60 | 22 | 33 | 15A |
| LPC16500A | 950 | 3.52 | 40 | 15.8 | 50 | 10A |
| LPC17420 | 950 | 3.52 | 40 | 17 | 42 | 5A |
| LPC20350 | 920 | 3.4 | 60 | 20 | 35 | 15A |
| LPC13600B | 900 | 3.33 | 80 | 13.5 | 61 | 1.2A |
| LPC13600C | 900 | 3.33 | 80 | 13.3 | 61 | 10A |
| LPC18350A | 900 | 3.33 | 80 | 18.3 | 36 | 1.2A |
| LPC18350C | 900 | 3.33 | 60 | 18 | 37 | 5A |
| LPC14500 | 870 | 3.22 | 50 | 14 | 52 | 8A |
| LPC13600A | 850 | 3.15 | 80 | 13.5 | 62 | 1.2A |
| LPC16420 | 850 | 3.15 | 40 | 15.8 | 42 | 5A |
| LPC17350 | 850 | 3.15 | 60 | 17 | 36 | 1.2A |
| LPC18350B | 850 | 3.15 | 40 | 18.5 | 36 | 10A |
| LPC18350D | 850 | 3.15 | 40 | 18.3 | 36 | 10A |
| LPC18400A | 850 | 3.15 | 40 | 17.2 | 41 | 12A |
| LPC14450 | 800 | 2.96 | 80 | 13.5 | 46 | 400mA |
| LPC16400 | 750 | 2.78 | 40 | 15.8 | 41 | 8A |
| LPC13450D | 720 | 2.66 | 80 | 13.3 | 46 | 3A |
| LPC13450A | 650 | 2.41 | 80 | 13 | 46 | 3A |
| LPC13450B | 650 | 2.41 | 80 | 13.5 | 46 | 1.2A |
| LPC13450C | 650 | 2.41 | 80 | 13.3 | 46 | 10A |
| LPC13440 | 600 | 2.22 | 80 | 13 | 44 | 600mA |
| LPC15350A | 600 | 2.22 | 40 | 15.3 | 36 | 8A |
| LPC12450 | 580 | 2.15 | 65 | 12.3 | 45 | 5A |
| LPC13350 | 500 | 1.85 | 60 | 13.3 | 35 | 5A |
| LPC13380 | 500 | 1.85 | 80 | 13 | 38 | 0.25A |
| LPC10600 | 470 | 1.74 | 70 | 10 | 60 | 5A |
| LPC14220 | 430 | 1.59 | 200 | 14.8 | 23 | 215mA |
| LPC18200 | 420 | 1.55 | 100 | 18.4 | 22 | 2A |
| LPC10500 | 400 | 1.48 | 80 | 10.5 | 51 | 3A |
| LPC13300 | 400 | 1.48 | 60 | 13 | 31 | 3A |
| LPC15350B | 350 | 1.3 | 80 | 15.3 | 35 | 1.2A |
| LPC80750 | 350 | 1.3 | 80 | 8.5 | 75 | 1.2A |
| LPC90570 | 350 | 1.3 | 65 | 9 | 57 | 3A |
| LPC95520 | 340 | 1.26 | 70 | 9.5 | 52 | 5A |
| LPC12300 | 310 | 1.15 | 80 | 12 | 30 | 5A |
| LPC10400 | 300 | 1.11 | 80 | 10 | 40 | 3A |
| LPC80500B | 300 | 1.11 | 85 | 8.4 | 49.5 | 300mA |
| LPC80620 | 300 | 1.11 | 80 | 8.5 | 62 | 1.2A |
| LPC90500 | 300 | 1.11 | 70 | 9 | 51 | 3A |
| LPC80570 | 280 | 1.04 | 80 | 8.3 | 57.5 | 1.2A |
| LPC10380 | 270 | 1 | 60 | 10 | 38 | 3A |
| LPC16270 | 270 | 1 | 80 | 16 | 27 | 1.2A |
| LPC80500A | 240 | 0.89 | 80 | 8.5 | 51 | 3A |
| LPC90430 | 220 | 0.81 | 70 | 9 | 43 | 3A |
| LPC80400B | 210 | 0.78 | 100 | 8.3 | 41 | 1.5A |
| LPC80450 | 210 | 0.78 | 80 | 8.5 | 44 | 1.5A |
| LPC75530 | 200 | 0.74 | 100 | 7.8 | 55 | 1.2A |
| LPC80460 | 200 | 0.74 | 80 | 8.3 | 47 | 3A |
| LPC10300 | 190 | 0.7 | 100 | 10.3 | 31 | 3A |
| LPC80400A | 180 | 0.67 | 80 | 8.5 | 41 | 2.5A |
| LPC75400 | 140 | 0.52 | 100 | 7.8 | 42 | 1.2A |
| LPC75380 | 120 | 0.44 | 140 | 7.5 | 37 | 120mA |
| LPC60500 | 100 | 0.37 | 350 | 5.8 | 52 | 50mA |
| LPC68380 | 90 | 0.33 | 140 | 7 | 39 | 1.2A |
| LPC70350 | 90 | 0.33 | 140 | 7.5 | 37 | 1.2A |
| LPC80250 | 80 | 0.3 | 200 | 8.5 | 25 | 1.5A |
| LPC10150 | 70 | 0.26 | 450 | 10 | 15 | 70mA |
FAQ :
lithium-polymer-batteries Performance:
- Stock largest capacity range in 8mAh-12000mAh.
- Enhanced safety with Japan IC & MOS protectors.
- Compact shape to fit your Mechanical design perfectly.
- Reasonable dimensions tolerances including swell space.
- High capacity lithium-polymer-battery can run a long time, and the life cycle of charging&discharging more than 500 cycles.
- Integrated assembly options : Molex/JST connectors &Integrated PCM: Over-discharge/Overcharge Protection & NTC-temperature control.
- Customize battery and capacity according to your specified dimensions.
- OEM & ODM services for special size of lithium polymer battery.
- Rigorous testing and charging before shipment to ensure the quality of all lithium polymer batteries.
How to order and get quotation,specifications?
- Just send e-mail to us, tell us the model of lithium-polymer-batteries and quantity, or you need FAQ including specifications, quotation, battery picture,You can get a good reply within 12hours.
What’s MOQ,Lead time and shippment?
- MOQ: more than 5pcs(it is in stock),we can sell it to you.Because we have understanding deeply that our customers need a small samples to test in startup phase of new project or new product design.
- Lead time: 3-4 days.If you need urgently to test, lithium-polymer-batteries will be the first choice.
- Shipment: UPS/DHL/Fedex Door to Door.We will be based on your delivery address to select the most suitable shipment. What’s more, the lithium-polymer-batteries will be rigorous tested and charged to 60% 3.7V before shipment to ensure the quantity of all lithium-polymer-batteries.
